OCTAVIUS® Detector 1500 MR

Array Detector for Linac and Patient QA at MR-Linacs

The OCTAVIUS Detector 1500 MR is a new concept of an ion chamber matrix in a plane for IMRT verification and quality control in MR guided radiotherapy.

Key Features

  • Suitable for use with OCTAVIUS 4D MR – the modular QA phantom
  • Active volume 4.4 mmx 4.4 x 3 mm3 per chamber
  • Detector spacing 7.1 mm center-to-center
  • Large field coverage: 27 cm x 27 cm
  • One single device for linac and patient-specific QA
  • Gold standard ionization chamber technology avoids detector ageing effects
  • Also suitable for IMRT plan verification
  • Outstanding detector and matrix design: 1405 vented ionization chambers

Technical Specifications

Detector type: Plane-parallel vented ionization chambers
Number of detectors: 1405
Detector size: 4.4 mm x 4.4 mm x 3 mm (0.06 cm³)
Detector spacing: 7.1 mm center-to-center
Max. field size: 27 x 27 cm²
Reproducibility: ≤ ± 0.5%
Dead time: zero
Repetition rate: 100 ms
Measured quantities: absorbed dose to water (Gy), absorbed dose rate to water (Gy/min)
Resolution: Dose: 0.1 mGy, Dose rate: 0.1 mGy/min
Measurement range: 0.25 ... 800 Gy/min
Reference point: 7.5 mm below the surface of the array
Housing material: PS, GRP (frame)
Dimensions: 467 mm x 300 mm x 22 mm (H x W x D)
Weight: 6 kg
Power supply: (100 ... 240) VAC; (50 ... 60) Hz
PC connection: Ethernet
